ULTRASCALE MODULES



AVAILABLE

Q1 2016

THE

KRM-3Z20-512

ZYNQ MODULES

ARE HERE !

GET

YOURS

KR builds Robot Swarm

at MoMath in NYC

exhibit opened December 14th 2014

Read more



FPGA Design Services

Knowledge Resources is a certified Xilinx Alliance partner and offers a full range of FPGA design services

Read more

Featured Projects

Recent News

Mike

July 2016

Our latest Module Family features MPSoC parts and offers the highest versatility, logic density, I/O count and processing power in a 75mm x 100mm form- factor. Our KRM-5ZUxx modules feature 4HP PL banks, 3HD PL banks, 2MIO banks, 4PS GTX transceivers and 24 PL GTH transceivers at up to 16Gbs. DDR4 memory can be populated by SODIMM and can accommodate modules up to 16GB. Inquire now for early access to samples, and further technical information.KRM-5ZUXX

KRM-5ZUXX
Read More
Mike

April 2016: A new QSG is available to clarify the customization and startup behavior of the KRC3600 carrier. Learn how to configure the SD card for the module of choice and how to set the various jumpers here

Read More
Mike

May 2016: Find the latest SDSoC 2016.1 support for the KRM-3Z70xx family of  Zynq modules here

Read More
Mike

February 2016 Meet us at the Xilinx SDSoC Event at the Novotol in Eindhoven on March 3rd 2016. We will present our full range of Modules, all with support for the cutting edge SDSoC environment from Xilinx.

See a demo of a KRM-3Z20 Zynq SOM do real time image processing and feature extraction in our swarm robot platform.

Read More
Mike

May 2016 : Updated Vivado scripts with support for the KRM-1Z7010 and KRC1710 carrier have been added. Validated with the new 2016.1 release of Vivado. Get the current version here

Read More
Mike

December 2015. All of the KRM-3xxx and KRM-1xxx modules have been verified to meet the criteria for safe power up and power down sequencing as outlined in Xilinx's AR# 65240.

Read More
Mike

KRM-1k Preview

Mike Stengle

July 2015, our latest member of the KRM SoM Product line up is the new KRM1ZQ10; a low-cost, compact 30x70mm SO-DIMM module featuring a Zynq 7010 (or 7020) SoC with 512MB RAM, 2 QSPI Flash memories for configuration, 100 PL IO's and 38 PS MIOs. The module runs on a single 3V3 Supply and provides up to 1.5A of regulated 1V8 for low power peripherals.

In addition to the full featured version, a reduced feature "micro controller" version with 512kB on chip program memory and 256kB on chip RAM (no

Read More
Webmaster

December 2014, Knowledge Resources developed and built the robots that are the heart of the physical installation of the soon to open robot swarm exhibit of the Museum of Mathematics in New York City (MoMath). The robots feature a novel optical tracking system that allows each of them to be "aware" of their position and orientation with sub mm accuracy. The tracking systems image analysis is implemented in VHDL and mapped into the fabric of a Xilinx SoC on Knowledge Resources KRM3Z20 Module. Tec

Read More
Mike

New Appnote

Mike Stengle

March 2015, a new application note describing the use of aurora IP blocks in conjuction with KRM project scripts and the KRM3510 subcarrier is available for download in the KRM3510 product section. The appnote illustrates how a designer can quickly achieve 8Gb serial connectivity via optical or elctrical SPF+ links when using a KRM-3Z30 (or higher) module on the KRM3500 series carriers.

Read More
Mike

March 2013  We are proud to announce the achievement of certified Xilinx Alliance partner for the second year in a row.  Our growing team of certified Xilinx developers are looking forward to serving our mutual client base with expertise and dedication.

Read More

Blogs

Mike

You may have read our previous Blog about how “perfect” our modules are, here you can read how we ke

Read More
Mike

SO, since our first attempt of creating the “perfect” FPGA module was quite successful, we decided t

Read More
Mike

OK, I admit there is no such thing as a "perfect" FPGA module, but one should at least try to come a

Read More
