Overview of Intel/Altera SoMs

KR now also offers Intel/Altera-based SoMs starting with a compact Agilex5 SoM aimed at industrial and edge applications and a high-end Stratix 10-based Direct RF SoM for the most demanding RF applications.

We’ll continue to expand our offering in this category in the coming months.

Overview of Intel/Altera SoMs

KR now also offers Intel/Altera-based SoMs starting with a compact Agilex5 SoM aimed at industrial and edge applications and a high-end Stratix 10-based Direct RF SoM for the most demanding RF applications.

We’ll continue to expand our offering in this category in the coming months.

Based on the Intel AgileX 5 SoM,
the KRIB features:

  • 24 28.1 Gbps transceivers
  • 80 HVIO
  • 40 HSIO
  • 44 HPSIO
  • 4 x 8GB 32 bit LPDDR4 RAM
  • QSPI and eMMC
  • Single 3V7 to 5V supply
  • 60 x 50 mm

Based on the Intel 10 AX-Series,
the KRM-10-S10RF features:

  • 8x RF ADC and DAC @ 64GS
  • 24H & 24E-tile transceivers
  • 56 LOGIC I/O
  • 44 HPS I/O
  • 4GB 40 bit DDR4 HPS RAM
  • 2 x 8GB 72 bit DDR4 ECC RAM
  • Single 12V supply
  • 120 x 90 mm
