KRM-4ZU47DR RFSoC Module

Product Description

KRM-4ZU47DR RFSoC Module with AMD RFSoC GEN3

A compact, high end FPGA module that features the AMD RFSoC embedded in a most versatile design so that it can be optimally utilized in a multitude of applications. Only a 12V supply is required as all FPGA and RAM voltages are generated on board. Everything from power sequencing, configuration and clock generation is implemented on board. The Dual 64Bit PL DDR4 RAM, operating at 2.4GT/s, provides the highest PL memory bandwidth of any currently available RFSoC module. Sixteen 28Gbit transceivers provide ample connectivity, on board dual QSPI and eMMC memories allow for a multitude of boot options and storage.

Key features:

SoD FPGA
AMD Zynq XCZU47DR

Processing System
Quad core A53 64 bit processors

Memory Options
4-8 GB of PS RAM @ 2400 MHz
2x 4-8GB of PL RAM @ 2400 MHz
1Gb QSPI configuration flash
8GB eMMC

Module I/O
8x High-speed RF ADCs @ 5.0 Gs
8x High-speed RD DACs @ up to 10.0 Gs
16x 32-Gbit PL Transceivers
4x 6-Gbit PS transceivers

On connectors:

• 2 x HD banks
• 2x MIO Bank
• BMC console
• Transceivers
• Analog
• JTAG

Clock Synthesizer
On module low jitter Clock synthesizer for transceivers
